si-2c

These units are designed for collar attachment to birds such as parrots or macaws with strong aggressive bills. These units can also be used on small & medium sized mammals who require a stronger transmitter casing than our normal epoxy coating.

Specifications

Model Weight Standard Life Lifespan range Dimensions: L x Diameter (mm)
SI-2C 11g 12 months 6-18 months 33 x 11
SI-2C 13g 18 months 12-24 months 40 x 11
SI-2C 15g 24 months 12-30 months 50 x 11

Frequency Range: 138 – 235 MHz.

Transmitter: Crystal controlled two-stage design pulsed by a CMOS multivibrator.

Pulse Width (standard): 24 milliseconds.

Pulse Rate (standard): 40 pulses per minute (ppm). Available from 20-120ppm.

Power Output: Set to use available battery power over the required transmitter life.

Activation: Removing an external magnet starts the transmitter. Replacing the magnet stops the transmitter.

Housing: The battery and transmitter are hermetically sealed in a brass case.

Antenna: Stranded stainless steel cable covered with a black nylon coating. Additional layers of shrinkable tubing reinforce the antenna at its base.

Options

Temperature (suffix “T”): An increase or decrease in temperature results in a corresponding increase or decrease in pulse rate. At the standard settings, the pulse rate changes from ~15 ppm at 0°C to ~40 ppm at 40°C. Each transmitter is supplied with a plotted calibration curve. This option adds ~0.05g to the finished weight of the transmitter.
